How to Convert a Zod Schema to a MongoDB JSON Schema

How to Convert a Zod Schema to a MongoDB JSON Schema

Learn how to effortlessly transform your Zod schemas into MongoDB-compatible JSON Schemas.

json schema mongodb typescript zod

TL;DR: I created a simple library that exports a single function which takes a Zod schema and then converts it to a MongoDB JSON Schema. Check it out on GitHub.

Before Zod v4

There are a couple of libraries out there that converts a Zod schema to a JSON Schema that can be used to annotate and validate MongoDB documents. Most of these libraries were created before Zod v4.

These libraries did the arduous task of mapping each Zod type to their equivalent MongoDB BSON type and uses some TypeScript hack to specify BSON types.

But the introduction of Zod v4 has made converting Zod schemas to MongoDB JSON Schemas a breeze. Zod v4 introduces two cool APIs that makes this simple to implement: z.toJSONSchema and .meta.

z.toJSONSchema converts Zod schemas to JSON Schemas. No more monotonous mappings, the library does it itself and outright better. .meta allows us to associate schemas with additional metadata that we can later access and use for whatever we want.

So if there’s a z.toJSONSchema API, why are we having this conversation? We should start using it immediately to convert our schemas, you would say. Well, I wish that was the case but it isn’t.

MongoDB supports draft 4 of JSON Schema. Yes, you can pass the target as draft 4 when converting with z.toJSONSchema. But even when you do that, the resulting JSON Schema still isn’t compatible with what MongoDB accepts. Surprising right?

While I said earlier that MongoDB supports draft 4 of JSON Schema, there was a part I didn’t add: it does so with some differences.

So, how do we solve this? Well, that’s the whole point of this article. Let’s get started.

The Differences

MongoDB JSON Schema is kind of a subset of the JSON Schema Draft 4. It adds one thing and removes few things.

The addition is:

  • bsonType keyword: You can consider this an extension of the type keyword in JSON Schema. type can either be "null", "boolean", "object", "array", "number", or "string". The bsonType can also be any of these values and more. With bsonType, you can use all of the BSON types supported by MongoDB.

The removals are:

  • Hypertext definitions which are used to define hyperlinks on instance data and provide additional information required to interpret JSON data.

  • Hypermedia and linking properties of JSON Schema, including the use of JSON references and JSON pointers.

  • The keywords $ref, $schema, default, definitions, format, and id.

  • The integer type.

  • Unknown keywords. For a list of the available keywords accepted, refer to the MongoDB docs.

Tackling the differences

Additions

Let’s talk about the extension first. Consider this code below and its output:

import z from "zod";


const zodSchema = z.object({
  name: z.string(),
  middleName: z.nullable(z.string()),
  address: z.object({
    street: z.string(),
    city: z.string(),
    zip: z.string().optional(),
  }),
  isStudent: z.boolean(),
  hobbies: z.array(z.string()),
  score: z.number(),
});


const jsonSchema = z.toJSONSchema(zodSchema);
console.log(JSON.stringify(jsonSchema, null, 2));
{
  "$schema": "http://json-schema.org/draft-04/schema#",
  "type": "object",
  "properties": {
    "name": {
      "type": "string"
    },
    "middleName": {
      "anyOf": [
        {
          "type": "string"
        },
        {
          "type": "null"
        }
      ]
    },
    "address": {
      "type": "object",
      "properties": {
        "street": {
          "type": "string"
        },
        "city": {
          "type": "string"
        },
        "zip": {
          "type": "string"
        }
      },
      "required": ["street", "city"],
      "additionalProperties": false
    },
    "isStudent": {
      "type": "boolean"
    },
    "hobbies": {
      "type": "array",
      "items": {
        "type": "string"
      }
    },
    "score": {
      "type": "number"
    }
  },
  "required": [
    "name",
    "middleName",
    "address",
    "isStudent",
    "hobbies",
    "score"
  ],
  "additionalProperties": false
}

As you should notice, the type keyword is what’s used to specify the types of properties in JSON Schemas. If we were to copy this and remove the $schema line, we could use it as a MongoDB JSON Schema validator and it would work!

So, there really isn’t really much to do here. Our task would be to add a way for the user to specify a BSON type when the Zod API doesn’t provide one.

Removals

MongoDB, as mentioned earlier, makes some removals from the JSON Schema Draft 4. When using z.toJSONSchema, we need to take note of where these removals might pop up.

The removals that has to do with Hypertext and Hypermedia isn’t a big deal. Because, in a Zod schema you can’t specify a links field that gets added to the top-level of the JSON Schema or additional keywords like media that gets added to a property of the JSON Schema.

Next is unknown keywords. How can you pass an unknown keyword to the MongoDB JSON Schema? There are two ways you could do it:

  • When you pass a Zod schema to z.toJSONSchema, it tries to convert it to a JSON schema. If the Zod schema contains an api that’s not representable in JSON schema (like z.int64() or z.date()), Zod will throw an error. But if the conversion succeeded, that means the converted schema doesn’t contain an “unknown” keyword that JSON Schema can’t recognize. But even then, the converted schema can still fail as a MongoDB validator because it might contain a “removed” keyword (like default). So, though the keyword is known to JSON Schema, MongoDB considered it removed hence unknown.

  • When you use .meta to add keywords that the JSON Schema itself doesn’t recognize, and converts it to a JSON Schema. The conversion may pass for the JSON Schema, but the resulting schema might fail as a MongoDB validator. In this, the keyword is both unknown to JSON Schema and MongoDB.

Next is removed keywords. Well, it’s straightforward and this brings us to another task to implement. We would need to traverse the JSON Schema, and remove the unsupported keywords.

Finally, the integer type. For the most part, you won’t encounter integer as long as you stick to using z.number(). This is because z.number() produces type: "number" and the number BSON alias matches the integer, decimal, double, and long BSON types.

You get the integer type when you do:

  • z.int() which corresponds to a 53-bit integer range, setting minimum to -2^53 and maximum to 2^53 - 1.
  • z.int32() which corresponds to a 32-bit integer range, setting minimum to -2^31 and maximum to 2^31 - 1.

So what do we do when we get the integer type? This brings us to another task to implement: convert the integer type to the equivalent BSON type (int, long or number) based on the minimum and maximum fields.

.meta

The next big question is how do we represent BSON types that are not available in Zod? Metadata is the rescue!

Zod v4 introduced the concept of metadata and registries. Basically, it’s a way to associate a schema with additional metadata, store that schema in a registry, and then have TypeScript enforce type safety for its metadata. Why would you want to add metadata? Well, we could use those metadata as documentation, generate code, validate forms, etc. The list is endless.

Where each schema can have it own registry it’s registered to, Zod provides a global registry that can be used to store metadata specifically for JSON Schema generation. When we add metadata to a schema to the global registry, all the metadata fields will be copied into the resulting JSON Schema when converted with z.toJSONSchema:

const emailSchema = z.string().register(z.globalRegistry, {
  title: "Email address",
  description: "Your email address",
});


const jsonSchema = z.toJSONSchema(emailSchema);
console.log(JSON.stringify(jsonSchema, null, 2));
{
  "$schema": "http://json-schema.org/draft-04/schema#",
  "type": "string",
  "title": "Email address",
  "description": "Your email address"
}

The global registry accepts the following metadata:

export interface GlobalMeta {
  id?: string;
  title?: string;
  description?: string;
  deprecated?: boolean;
  [k: string]: unknown;
}

id, title and description are all valid keywords in JSON Schema Draft 4, but deprecated isn’t—it was added in a later draft. The index signature allows the global registry to have any number of additional metadata with a value of any type.

Instead of doing .register(z.globalRegistry, {...}), we can simply use .meta({...}) to add metadata to the global registry.

With .meta we can add whatever metadata we like to a schema. Of course, we don’t want to do that, since all hell will break loose. So, what exactly do we want? the bsonType keyword. Using .meta({ bsonType: "..." ), we want to specify the types for properties we want if they’re not available in Zod.

This brings us to the next task to implement: globally augment the GlobalMeta interface, so we get TypeScript intellisense for bsonType in .meta.

Abuse and incorrect use of .meta

Yes, using .meta we can specify a bsonType:

const zodSchema = z.object({
  _id: z.unknown().meta({ bsonType: "objectId" }),
});


const jsonSchema = z.toJSONSchema(zodSchema);
console.log(JSON.stringify(jsonSchema, null, 2));
{
  "$schema": "http://json-schema.org/draft-04/schema#",
  "type": "object",
  "properties": {
    "_id": {
      "bsonType": "objectId"
    }
  },
  "required": ["_id"],
  "additionalProperties": false
}

But the challenge is we can specify anything inside .meta and it wouldn’t fail in z.toJSONSchema:

const zodSchema = z.object({
  dob: z.unknown().meta({ whatever: "trash" }),
});


const jsonSchema = z.toJSONSchema(zodSchema);
console.log(JSON.stringify(jsonSchema, null, 2));
{
  "$schema": "http://json-schema.org/draft-04/schema#",
  "type": "object",
  "properties": {
    "dob": {
      "whatever": "trash"
    }
  },
  "required": ["dob"],
  "additionalProperties": false
}

This means .meta can be abused to add properties that would pass in z.toJSONSchema but fail in MongoDB JSON Schema.

Secondly, .meta can be used incorrectly. Consider this code below and its output:

const zodSchema = z.object({
  name: z.array(z.string()).meta({ bsonType: "string" }),
});


const jsonSchema = z.toJSONSchema(zodSchema);
console.log(JSON.stringify(jsonSchema, null, 2));
{
  "$schema": "http://json-schema.org/draft-04/schema#",
  "type": "object",
  "properties": {
    "name": {
      "bsonType": "string",
      "type": "array",
      "items": {
        "type": "string"
      }
    }
  },
  "required": ["name"],
  "additionalProperties": false
}

Did you see items? That’s wrong! A string shouldn’t have items. It doesn’t even make sense.

So, the question is how do we build a robust implementation where .meta can be used to specify bsonType but not abused and used incorrectly?

There are two ways we could approach it:

  1. Implementation-controlled: In this approach, the user can use whatever schema they want and add .meta to it. In the resulting schema, we would go through each property and then find a way to handle it internally, so that it’s MongoDB-compatible. Like in the example above where string has items, we would remove items. I guess, you can see where this will lead us to? Re-implementing the entire JSON Schema!

  2. User-controlled: In this approach, the user is in full control. This means to have a MongoDB-compatible JSON Schema, the user is advised to rely on their Zod schema only. .meta should only be used to specify title, description and BSON types not available in Zod. Anything outside these uses, the user is assumed to know better and bears full responsibility.

I think (2) makes more sense, so we would go with that.

Building the solution and shipping it

With us understanding what the Zod library itself provides, why the JSON Schema it returns isn’t MongoDB-compatible, how to fix it, and the design decisions we’ll use, it’s time to write code.

For the sake of brevity, I won’t be explaining each line of code. I did my best to provide comments where it made sense, and if you understand recursions, then the code should be easy to grasp.

There you have it:

import z from "zod";


declare module "zod" {
  interface GlobalMeta {
    bsonType: string;
  }
}


// JSON Schema keys not supported by MongoDB's `$jsonSchema` operator
const UNSUPPORTED_KEYS = [
  "$ref",
  "$schema",
  "default",
  "definitions",
  "format",
  "id",
] as const;


function _typeForInteger(json: Record<string, any>) {
  // Only process JSON Schemas with type as `"integer"`
  if (json.type !== "integer" && json.bsonType !== "integer") {
    return json.bsonType;
  }


  const INT32_MIN = -2_147_483_648; // 2^31 * -1
  const INT32_MAX = 2_147_483_647; // 2^31 - 1
  const INT53_MIN = -9_007_199_254_740_991; // -(2^53 - 1)
  const INT53_MAX = 9_007_199_254_740_991; // 2^53 - 1
  const INT64_MIN = -9_223_372_036_854_775_808n; // -(2^63)
  const INT64_MAX = 9_223_372_036_854_775_808n; // 2^63 - 1


  const min = json.minimum ?? INT53_MIN;
  const max = json.maximum ?? INT53_MAX;


  // If the range is exactly the standard 32-bit or 53-bit, or no
  // custom range was specified, then let MongoDB enforce the limits.
  if (
    (min === INT32_MIN && max === INT32_MAX) ||
    (min === INT53_MIN && max === INT53_MAX) ||
    (json.minimum === undefined && json.maximum === undefined)
  ) {
    delete json.minimum;
    delete json.maximum;
    return min < INT32_MIN || max > INT32_MAX ? "long" : "int";
  }


  // If a custom range is specified, then let the range decide.
  // Zod automatically adds `minimum` and `maximum` for `int32` and `int`,
  // even if the user only specifies one of them. In such cases, the "other"
  // boundary is artificially added by Zod. We want to detect those
  // automatically added fields and remove them so that MongoDB enforces its
  // default min/max limits for the type.
  if (min >= INT32_MIN && max <= INT32_MAX) {
    if (json.minimum === INT32_MIN) delete json.minimum;
    if (json.maximum === INT32_MAX) delete json.maximum;
    return "int";
  }


  if (BigInt(min) >= INT64_MIN && BigInt(max) <= INT64_MAX) {
    if (json.minimum === INT53_MIN) delete json.minimum;
    if (json.maximum === INT53_MAX) delete json.maximum;
    return "long";
  }


  // Integers beyond 64-bit integers (rare)
  return "number";
}


function _isPropertiesMap(object: any): boolean {
  if (!object || typeof object !== "object") {
    return false;
  }


  return Object.values(object).every(
    (v) => v && typeof v === "object" && ("type" in v || "bsonType" in v),
  );
}


function _sanitizeSchema(schema: any, inProperties = false): any {
  if (Array.isArray(schema)) {
    return schema.map((element) => _sanitizeSchema(element, inProperties));
  }


  if (!schema || typeof schema !== "object") {
    return schema;
  }


  const sanitized: Record<string, any> = {};


  for (const [key, value] of Object.entries(schema)) {
    // Determine if this key's value is an actual "properties" map
    const isPropertiesMap = key === "properties" && _isPropertiesMap(value);


    // If not inside a properties map, then skip unsupported JSON Schema keywords
    if (!inProperties && UNSUPPORTED_KEYS.includes(key as any)) continue;


    sanitized[key] = _sanitizeSchema(value, isPropertiesMap);
  }


  // Handle numeric type conversion
  if (sanitized.type === "integer" || sanitized.bsonType === "integer") {
    sanitized.bsonType = _typeForInteger(sanitized);
    delete sanitized.type;
  }


  // For consistency, only represent `number` with keyword `type`
  if (sanitized.type === "number" || sanitized.bsonType === "number") {
    sanitized.type = "number";
    delete sanitized.bsonType;
  }


  return sanitized;
}


export default function zodToMongoSchema(zodSchema: z4.$ZodType) {
  if (!zodSchema) return {};


  // Convert to JSON Schema Draft 4
  const rawJsonSchema = z4.toJSONSchema(zodSchema, { target: "draft-4" });


  // Sanitize to make it MongoDB-compatible
  return _sanitizeSchema(rawJsonSchema);
}

MongoDB is the primary database I work with and Zod at this point is invisible. We create libraries for solutions we would likely use across projects, over and over again. I think in the future, when I need to annotate and validate a MongoDB document, I would likely come for this utility. So, yeah, it deserves to be a library.

I created the zod-to-mongo-schema package you can install to use this utility. You can also find the code and a detailed documentation on GitHub.

Conclusion

If you read the whole post and got to this point, you’re the real boss. It means your attention span hasn’t be hijacked by AI summaries. Please guard it with grace.

Remember, “hackers hack, crackers crack, and whiners whine. Be a hacker.” Thanks for your time.
